Eruption.

One of the world’s greatest guitar solos. From the debut album by Van Halen in 1978. This solo came bursting onto the scene with its innovative tone, two handed tapping and extreme tremolo bar use.

At the time, a young Eddie Van Halen was getting an incredible tone out of his 1968 Marshall “Plexi” Superlead Amplifier. The amount of gain coming from a supposedly “stock” Marshall didn’t make any sense to most guitarists.

Eddie had also bucked the status quo by gouging out a space for a humbucker pickup in the bridge position of his otherwise normal 3 single coil Strat body. By any measure, it’s an awesome tone and launched Edward Van Halen to the status of Guitar Legend.

To recreate this tone, I’m going to use the BOSS GT-1, entry-level, multi-effects unit. While it’s great if you can afford all of Eddie’s original rig (or buy a small island for the same money), that still doesn’t help you simulate all of the other elements of the recording process, which I’ll explain in a moment.

This is a fairly simple tone as far as the basic components of the recording go. A humbucker equipped guitar, a Marshall Plexi, a phaser effect that gives the tone some movement and a fairly large reverb effect. But as they say, “The Devil is in the Detail”. Getting the correct EQ settings for the amp and the correct space for the reverb makes this more of a challenge than it might first appear.

Firstly, let’s break down the components of tone in a process I call, the 4 Elements of Tone.

DOWNLOAD FREE PATCH NOW!
Visit guitarfxpatches.com and download free guitar tone from Eruption using Discount Code: GT1ERUPTION


Contributed by Josh Munday – Tone Designer for the Roland Australia Blog

1. The Guitar

GuitarEddie would have used his fledgling Frankenstrat, with a humbucker he had taken out of a Gibson and wax potted himself (ruining many pickups while perfecting this process). I used a Mexican Fender Strat in the video for this tone design segment that has a single coil in the bridge. In the GT-1, there is a setting for converting my single coil into a humbucker which I’ll go through in the Pickup Selection section of this article. I like to use very “plain” and familiar sounding guitars for tone design, because it’s easier for others to replicate and shows that this is possible even with basic/affordable gear (i.e. Mexican Strat + GT-1).

2. The Pickup Selection

Guitar PickupThis is definitely a bridge pickup tone (at the time it might have been the only pickup that was operational on Eddie’s guitar anyway). We can tell this by how bright the tone is. Because I only have a single coil in the bridge position, I’m going to use some of the magic in the GT-1’s Effects Section, to change the tone of the single coil into something more resembling a humbucker tone.

To do this, go to the FX-1/COMP section in the signal chain, select GUITAR SIMULATOR as the type of effect (this section contains many different effects), then select S-H (Single Coil – Humbucker). I’ve left the LOW setting at 0 and boosted the HIGH slightly to 2 and LEVEL at 50. If you have a guitar with a single coil in the bridge, you will notice a change to the tone as soon as you turn this effect on.

3. The Amp

Guitar AmpOf course, this was Edward’s legendary 1968 Marshall Plexi Superlead 100 watt amplifier head into a 4 x 12″ speaker cabinet. The exact settings that he was running are unknown, but he was famous for cranking every knob to FULL!

When selecting an amp, there are some basic rules of thumb that will help:

ALWAYS START WITH EVERYTHING OFF!!!

I can’t stress this enough. Find the OFF button for everything in the signal chain, so all you can hear is your dry old guitar sound coming through. Remember any multi-FX/amp simulator like the BOSS GT-1 is just simulating a room full of gear, so think about it like that. You wouldn’t walk into a room full of amps and FX and start by turning everything ON would you? You would plug into an amp, get a good basic tone, then turn on any effects, one at a time and build up your sound…likewise with any multi-FX!

  • Set the EQ “flat” (i.e. all settings at the halfway point or 12 o’clock). This gives you a neutral starting point so that the EQ isn’t colouring the tone too much yet.
  • Put the gain up to about a quarter to half a turn so you can hear the gain character.


We’re looking for a tone that resembles a Marshall Plexi, so in the PREAMP Section of the signal chain I’ve selected the MS1959 I+II setting. This will give us an approximation of the basic tone to begin with.

Now onto the EQ settings.

I’ll often use quite extreme EQ settings, remember that we’re trying to reproduce the “recorded” version of this tone, which means that even though Eddie might not have been running these EQ settings, the mixing and mastering processes can change the tone. So we might need to make adjustments that seem a little “outside the box”.
The settings I’ve chosen are:

  • BASS – 50
  • MIDDLE – 98
  • TREBLE – 100
  • PRESENCE – 80


As well as the EQ setting for the amp, I’ve also used the EQ that is within the MASTER SETTINGS part of the signal chain to tweak the tone some more. Boosting or cutting the EQ on the Amplifier Simulator has a different effect on the tone than the MASTER SETTING part. Think of the AMP EQ as changing the EQ on the Virtual Amplifier and the MASTER SETTINGS EQ as changing the EQ on the mixing board after it has been recorded.

The setting I’ve selected in the MASTER SETTINGS section are:

  • PATCH LEVEL – 128
  • LOW GAIN – 1
  • MID GAIN – 4
  • MID FREQ – You can also select the frequency of the midrange in this part, so I set this to 1.00kHz to try and simulate the specific upper midrange frequency of the recording.
  • Q MID – 1. The “Q” determines how much the frequencies surrounding the midrange frequency you’ve set will be affected. The lower the number, the more frequencies surrounding the MID FREQ setting will be affected when you boost or cut in the MID GAIN Setting.
  • HIGH GAIN – 0


I’ve cranked the GAIN all the way up to 95 because of the amount of sustain and crunch we want. And I’ve left the Speaker Type setting on ORIGINAL. Any time you leave the setting on ORIGINAL it selects the speaker type most commonly used with that amplifier type.

That should start to get us close to that Marshall recorded tone. Now to the effects.

4. The Effects

GT-1Before we get started on the effects section, I just want to explain what I mean by “Effects”. This can mean not only traditional effects that you would run in the main input or in the effects loop of your amplifier, (such as overdrive pedals, chorus, etc) but also any effects that were added later in the mixing process or “Post-Production” effects.

These can include delays for example, which are often added after the track has been recorded and would not have been heard by the guitarist at the time of recording. Other elements that I would count in the effects section are:

  • EQ and Compression that were adjusted in the mixing stage.
  • The microphone that is on the speaker cabinet. What did it sound like?
  • Was there a second microphone in the room, away from the speaker cabinet?
  • How far away from the speaker cabinet was the mic?
  • How loud is that second mic in the mix?
  • What did the room sound like from that room mic?
  • etc…etc…etc….and on and on it goes.


Now, this is starting to sound super complicated right? Well, let’s just go through each part step-by-step and I’ll take you through how we can simulate some of these elements.

For this recording, I can’t really hear any audio characteristics that resemble a room mic, so we don’t need to worry about that. But, for more details on the process of simulating a room mic, please see my other article – Jimi Hendrix’s “Voodoo Child (Slight Return)” Deconstructed.



Phaser
The classic phaser effect has been a mainstay of EVH’s tone for as long as we’ve been hearing him. He’s been quoted as saying, “Suddenly it became a different sound, which helped me stand out in the mix, because back then, in the club days, we usually had lousy P.A. systems and lousy sound guys. It didn’t boost the signal, but it made it pop out so the solo was more audible. It enhanced the tone.”

He also used quite a slow rate on the phaser so it was more of a tone changer that an obtuse phasing effect. Now, because we’ve used FX1 to modify our pickup tone, we’ll use the FX2 section of our signal chain to add the phaser.

The settings I’ve used are:

  • TYPE – PHASER
  • 4STAGE
  • RATE – 30 (pretty slow as that’s how he uses it)
  • DEPTH – 39
  • RESO – 12
  • MANUAL – 55
  • EFFECT LEVEL – 100


Reverb
The reverb that’s on this tone has been added in the mixing process and is not natural from the room it was recorded in (unless it was recorded in St Pauls Cathedral!)

To simulate the specific reverb, I’ve used the following settings in the REVERB section of the signal chain:

  • TYPE – PLATE (this is a lush, spacious sounding reverb that’s perfect for this tone)
  • TIME – 2.5s
  • E.LEVEL – 87 (that’s a lot of reverb folks!)
  • Over the page, you will see 2 more settings – LOW CUT and HIGH CUT. These 2 settings dictate how large a frequency band that you will hear the reverb in. Since this is an older recording, it’s more limited in the range that you hear in the recording. Often on guitar recordings, you don’t need a full range reverb, so I’ve cut everything from 160Hz down and 4kHz up.


Settings are:

  • LOW CUT – 160Hz
  • HIGH CUT – 4.00kHz


Pedal Bend
DANGER WARNING: Ok, so this is only for the guitarists without a Whammy Bar that stays in tune, or have a stoptail piece like a Les Paul. This effect will enable you to perform Whammy Bar-like functions using the GT-1 Expression Pedal instead of an actual bar.
Setting are:

  • PEDAL FX
  • TYPE – PEDAL BEND
  • PEDAL POSITION – 100
  • PITCH – “-12”
  • EFFECT LEVEL – 100


The only trick you need to know about this effect is that you need to have the pedal in the “Heel” position to start with in order to be at concert pitch. So the drop in pitch is activated by pushing forward (not Toe to Heel).

And that’s it!

There you have it guys, the guitar tone from Eruption by Edward Van Halen. If you have a GT-1 and don’t want to have to program this tone yourself, you can download it from my website.
Just enter this Discount Code and you can get it for FREE!

Website = guitarfxpatches.com
Discount Code = GT1ERUPTION
