So you’ve splashed out on the TD-50 kit… CONGRATULATIONS!

We know that you’re busting to jump on and start playing, so we’ve put together a list of essential must do’s to give you the best possible experience.

Contributed by Simon Ayton for the Roland Australia Blog

1. Setting up the Rack – Left or Right handed?

Right-handers:
First, lay the two curved pieces down on the floor, with the straight ended jacks labelled kick, toms etc exiting to the far left corner. That’s where the module will go.









The third curved pole to the far right should have no cables running through it.

Lefties:
Reverse this so that straight ended jacks exit the far right corner of the rack.









2. Set up the kick

Kick Drum
Attach the KD-A22 to your own 22” kick following the supplied steps carefully. Alternatively, set up the supplied KD kick trigger.

With the KD-140 trigger, the leg length determines the angle at which the kick beater will make contact with the head.

To avoid excess bounces and double hits, adjust the angle of the kick head surface back from 12 o’clock when viewed side-on, so that the swinging beater doesn’t hit the head twice. This is done by reducing the length of the legs.







































With the KD-120 kick trigger, simply loosen the clamps holding the pad and rotate the trigger pad on the shaft to adjust the optimum angle.

tip



3. Connect the toms and snare

snear
You can set up the toms as per the pictures, with one up (T1) and two down (T3, T4) or two up (T1, T2) and one down (T3) for a conventional looking five piece kit.

For this second option, insert tom 2’s rod holder directly into the rack pole and move the ride to the first floor tom’s clamp position.

Place the snare on a conventional snare stand. Connect the supplied USB lead to the snare and from the snare, into any of the digital USB connections of the TD-50 module.

Clip down the cable lock to ensure a reliable connection whilst playing

tip



4. Mount and connect the cymbals.

cymbal
V-stopper The clamping screws of the supplied V-stoppers need to be loosened before tightening to the cymbal arm.

Cymbals mount directly onto the V-stoppers, which are designed to stop cymbals from spinning. The felt then goes on, followed by the wing-nut.

Attach the supplied USB cable between the CY-18DR ride and any of the module’s digital USB inputs. Ensure the USB connector clip is fastened to keep the USB connector secure during performance.

tip



5. Mount and connect the module

module
Screw the supplied mounting plate onto the module and connect all the straight jacks to the trigger inputs as marked.

If the jacks are ‘L’ shaped, you’ve set up the rack incorrectly so please go to Step 1 and confirm that straight jacks exit nearest the module.

6. Mount the Hi-Hat

Hi-hat
VH-11 (TD-50K)

  • Loosen off the tilt adjuster on the hi-hat stand so that it’s flat.
  • The big metal felt washer goes on first, rubber side up.
  • HHC goes on next. Connect the ‘L’ shaped lead marked ‘HHC’.
  • Top hat goes on and connects with the HH lead.



VH-13 (TD-50KV)
strap

  • Loosen off the tilt adjuster on the hi-hat stand so that it’s flat.
  • Bottom hat goes on, with the small raised triangle facing in toward the player.
  • Fit the clutch to the top hat with the metal washer on top, between the top hat and the clutch.
  • Connect the hi-hat link lead inside, between the top and bottom hats.
  • Choose small ‘S’, medium ‘M’ or large ‘L’ hi-hat straps depending on the diameter of your hi-hat stand and fit it between the bottom of the hi-hat and stand to stop the lower hat from spinning.



*Connect the HHC and HH connectors and use the rubber cable-tie to keep the hi-hat leads contained. Connector labelled ‘HH’ goes to the left side of the hi-hat to the trigger output.

7. Tidy up the cabling

Use the supplied clips to take up the slack in the cables.

Clip the jack leads for toms and cymbals into their rubber holders so that they don’t vibrate or interfere with the triggers, which can cause false-triggering and excess wear.

8. Module start and first time setup

module
Once the module has started – IT’S ALMOST TIME TO PLAY!


But first, you must choose your kit trigger configuration and calibrate the hi-hat.

Choose the kit Configuration
*Press [TRIGGER]-[F1] (BANK) and use the UP cursor to highlight the bank number.

*Use the [+ ] or [-] buttons to select your particular TD-50 configuration:

TD-50K (default),
TD-50 Screen









TD-50KV + KD-140
TD-50 Screen









TD-50KV + KD-A22
TD-50 Screen









Calibrate the hi-hat

VH-11
* Press [TRIGGER], [F4] (hi-hat).
* Loosen the top hi-hat clutch.
* Use the open-close knob on the top of the hi-hat to centre the indicator between the arrows.

VH-11













It’s calibrated or ‘zeroed’ when both left and right triangles are highlighted.

TD-50 screen







*You can now press [KIT] or [EXIT] to begin playing.

VH-13
*Press [F5] (OFFSET).
*Loosen the hi-hat top clutch and press [F5] (execute).
TD-50 screen







*When completed press [KIT] or [EXIT] to begin playing your TD-50!

9. Done. Enjoy your TD-50 and remember to eat and sleep!

Download the PDF TD-50 Quick Start Guide here.
